EMR Series
Earthmover Radial Tires 1042
The Trelleborg EMR range is designed to enhance productivity in critical construction applications, delivering both enhanced damage protection and durability while the multi surface tread design delivers control and perfect grip when it’s needed the most, whether on sand, rock, gravel or soil.
Designed for articulated dumper and suitable for loader applications, our EMR1042 tire is the best choice for haulage operations in open pits and quarries and also suitable for infrastructure and building construction and landscaping.
The new PRO-PIT construction represents an enhanced evolution of the range, featuring an Cut resistant compound, reinforced casing, and wider, stronger beads. Together, these upgrades deliver extended tire life and exceptional performance in the harshest operating conditions.
Main Benefits
• Supreme traction in sand and gravel• Excellent tire life due to deep tread
• High comfort
• Extended tire life Find your Dealer
The Performance you need
Downloads
Technical Data
| Tire size | Tread pattern | TRA Code |
Rim size (Permitted) | Tread depth (mm) | Service description LI/SS Loader/Transport |
Tire load capacity (kg) at 10 (km/h) | Tire pressure (bar) | Tire load capacity (kg) at 50 (km/h) |
Tire pressure (bar) |
| 23.5 R 25 | EMR1042 | L4/E4 | 19.50/2.5-25 | 51 | ** 201 A2/185 B |
14500 | 5,75 | 9250 | 4,50 |
| 26.5 R 25 | EMR1042 | L4/E4 | 22.00/3.0-25 | 54 | ** 209 A2/193 B |
18500 | 5,75 | 11500 | 4,50 |
| 29.5 R 25 | EMR1042 PRO-PIT | L4/E4 | 25.00/3.5-25 | 58 | ** 216 A2/200 B |
22400 | 5,75 | 14000 | 4,50 |
| 875/65 R 29 | EMR1042 PRO-PIT | L4/E4 | 28.00/3.5-29 | 62 | ** 221 A2 /203 B |
25750 | 6,25 | 15500 | 4,25 |
